Concrete/Cement Hose

Product Detail

Product Tags

Construction
Tube: synthetic rubber, wear resistant and impact?resistant (NR+BR).
Reinforcement layer:High tensile textile
Cover rubber:NR+SBR
Safety factor:3:1
Working temperature:—20℃(-4℉) ~80℃(+176℉)

Application: Abrasion resistant tube and cover fabricated with highest quality material. Used in the transfer of dry materials & slurry and ideal for dry cement, pebble lime and other abrasive media.

Characteristics
The inner rubber is made of high wear-resistant synthetic rubber, and its thickness varies according to different sizes, which can meet the actual needs of various working conditions. Because of its use of polyester reinforced layer, it is more light and convenient to operate in some working conditions

Engineering
1.All hoses are manufactured in our own plant with ISO 9001:2008 registered quality management systems.
2.NBR Food hoses are suitable for use with food process FDA required.
3.ZEBUNG Marine Hose have been approved the OCIMF-GMPHOM 2009 certificate by BV for the single carcass floating oil hose and submarine hoses.
4.Patent For Rubber composite soft pipe of conveying LPG, LNG and severe corrosive chemical solvent

I.D.		?O.D.	?W.P.		B.P.		Tube?thickness	Weight	Length
mm	inch	mm	psi	bar	bar		mm	kg/m	ft	m
51	2"	66	150	10	450	30	4	1.73	200/130	61/40
64	2-1/2"	80	150	10	450	30	4	2.4	200/130	61/40
76	3"	94	150	10	450	30	4	3.18	200/130	61/40
102	4"	121	150	10	450	30	4	4.26	200/130	61/40
127	5"	146	150	10	450	30	4	5.55	200/130	61/40
152	6"	173	150	10	450	30	4	7.27	200/130	61/40

Own film production base

The quality of film directly determines the quality of hose. Therefore, zebung has invested a lot of money to build a film production base. All hose products of zebung adopt self-produced film.

Multiple production lines to ensure production progress

Our factory has many modern production lines and a large number of experienced technical engineers. It not only has high quality production quality, but also can ensure the customer's requirements for the supply time of products.

Each pipeline product is subject to strict inspection before leaving the factory

We have established a high-tech product and raw material testing laboratory. We have been committed to the digitization of product quality. Each product needs to go through a strict inspection process before it can leave the factory after all product data meet the requirements.

Covering the global logistics network and strict finished product packaging and delivery process

Relying on the distance advantages of Tianjin port and Qingdao port, Beijing Capital International Airport and Daxing International Airport, we have established a fast logistics network covering the world, basically covering 98% of countries and regions around the world. After the products are qualified in the off-line inspection, they will be delivered at the first time. At the same time, when our products are delivered, we have a strict packing process to ensure that the products will not cause losses due to logistics during transportation.
